Good Condition Used XCMG 26U Excavator For Sale
Rated power
15.4kw/2400rpm
Operation Weight
2780Kg
Bucket capacity
0.06m³
XE26U
The hydraulic excavator is equipped with a low-speed high-torque engine with high efficiency and low fuelconsumption. The maintenance parts are moved outwards, the maintenance period is extended, the maintenance is more convenient; a variety of optional accessories, as well as altitude adaptive control functions, the environment adaptability is better. It can be widely used in small and medium-sized earth and stone works, highway and bridge construction, trenching and construction, farmland water conservancy, river dredging and municipal construction. It can also achieve different operations such as digging, crushing and dismantling, and is highly adaptable to working conditions.
PARAMETERS
| Model | Unit | Measurement | |
| Operating weight | Kg | 2780 | |
| Bucket capacity | m³ | 0.06 | |
| Engine | Model | / | D1105 |
| Direct injection | / | – | |
| Four strokes | / | √ | |
| Water cooling | / | √ | |
| Turbo-charging | / | – | |
| No. of cylinders | / | 3 | |
| Output power | kw/rpm | 15.4/2400 | |
| Maximum torque/speed | N.m | 70.3/1600 | |
| Displacement | L | 1.123 | |
| Main performance | Travel speed | km/h | 3.6/2.4 |
| Swing speed | r/min | 10 | |
| Gradeability | ° | ≤30 | |
| Ground pressure | kPa | 26.3 | |
| Bucket digging force | kN | 23 | |
| Arm digging force | kN | 14 | |
| Maximum traction | kN | 29.7 | |
| Hydraulic system | Rated flow of main pump | L/min | 82.8 |
| Main safety valve pressure | MPa | 24.3 | |
| Travel system pressure | MPa | 24.3 | |
| Swing system pressure | MPa | 16.2 | |
| Pilot system pressure | MPa | 3.5 | |
| Oil Capacity | Fuel tank capacity | L | 33 |
| Hydraulic tank capacity | L | 22 | |
| Engine oil capacity | L | 5.1 | |
| Appearance size | A Overall length | mm | 4190 |
| B Overall width | mm | 1500 | |
| C Overall height | mm | 2580 | |
| D Width of platform | mm | 1350 | |
| E Overall width of chassis | mm | 1500 | |
| F Track width | mm | 300 | |
| G Tread | mm | 1560 | |
| H Track gauge | mm | 1200 | |
| I Counterweight clearance | mm | 535 | |
| J Min. ground clearance | mm | 290 | |
| Dozer(width/height) | mm | / | |
| Working scope | A Max. digging height | mm | 4390 |
| B Max. dumping height | mm | 3120 | |
| C Max. digging depth | mm | 2800 | |
| D 最 Max. vertical wall digging depth | mm | 2310 | |
| Max. digging radius | mm | 4750 | |
| Min. swing radius | mm | 1980 | |
| Min. tail turning radius | mm | 790 | |
| Max. lifting height of dozer | mm | 300 | |
| Max. digging depth of dozer | mm | 330 | |
| Standard configuration | Length of boom | mm | 2090 |
| Length of arm | mm | 1300 | |
| Bucket capacity | m³ | 0.06 | |
| Optional configuration | Bucket capacity | m³ | 0.026/0.042/0.06/0.13 |
| / | |||
| Auxiliary equipment and others | / | / | |
