Good Condition XCMG 35U Used Excavator For Sale
Rated power
103kw/1600rpm
Operation Weight
4200/4100Kg
Bucket capacity
0.12m³
XE35U
The hydraulic excavator is equipped with a low-speed high-torque engine with high efficiency and low fuelconsumption. The large undercarrige and pilot buffer are more stable and comfortable to operate; the maintenance parts are moved outwards, the maintenance period is extended, the maintenance is more convenient; a variety of optional accessories, as well as altitude adaptive control functions, the environment adaptability is better. It can be widely used in small and medium-sized earth and stone works, highway and bridge construction, trenching and construction, farmland water conservancy, river dredging and municipal construction. It can also achieve different operations such as digging, crushing and dismantling, and is highly adaptable to working conditions. It can be equipped with multifunctional work attachments, tailless design, flexibility and versatility, the largest driving space in its class, and cold and warm air conditioning.
PARAMETERS
| Sales model | Unit | Measurement | |
|---|---|---|---|
| Operating weight | Kg | 4200/4100 | |
| Bucket capacity | m³ | 0.12 | |
| Engine | Model | / | 3TNV88-Z |
| Direct injection | / | × | |
| Four strokes | / | √ | |
| Water cooling | / | √ | |
| Turbo-charging | / | × | |
| Air cooled | / | 3 | |
| No. of cylinders | / | 22.2/2400 | |
| Output power | kw/rpm | 103/1600 | |
| Maximum torque/speed | N.m/rpm | 1.642 | |
| Displacement | L | 3.6/2.2 | |
| Main performance | Travel speed | km/h | 9 |
| Swing speed | r/min | ≤30 | |
| Gradeability | ° | 36.6 | |
| Ground pressure | kPa | 28.6 | |
| Bucket digging force | kN | 20.3 | |
| Arm digging force | kN | 31.6 | |
| Maximum tractive force | kN | 108 | |
| Hydraulic system | Rated flow of main pump | / | 23 |
| Rated flow of main pump | L/min | 21 | |
| Main safety valve pressure | MPa | 16.7 | |
| Travel system pressure | MPa | 3.9 | |
| Swing system pressure | MPa | 40 | |
| Pilot system pressure | MPa | 45 | |
| Oil Capacity | Fuel tank capacity | L | 7 |
| Hydraulic tank capacity | L | 4970 | |
| Engine oil capacity | L | 1740 | |
| Appearance size | A Overall length | mm | 2550 |
| B Overall width | mm | 1480 | |
| C Overall height | mm | 1740 | |
| D Width of platform | mm | 300 | |
| E Track length | mm | 1721 | |
| F Overall width of chassis | mm | 1440 | |
| G Track width | mm | 587 | |
| H Length to center of rollers | mm | 297 | |
| I Track gauge | mm | / | |
| J Counterweight clearance | mm | 5000 | |
| K Min. ground clearance | mm | 3600 | |
| L Min. tail swing radius | mm | 3060 | |
| M Track height | mm | 2260 | |
| Working scope | A Max. digging height | mm | 5300 |
| B Max. dumping height | mm | 2170 | |
| C Max. digging depth | mm | 870 | |
| D Maximum depth cut for 2240mm(8 ft) level bottom | mm | 305 | |
| E Max. vertical wall digging depth | mm | 360 | |
| Max. digging radius | mm | 2560 | |
| Min. swing radius | mm | 1350 | |
| Standard configuration | Length of boom | mm | 0.12 |
| Length of arm | mm | / | |
| Bucket capacity | m³ | / | |
| Optional configuration | Length of boom | m³ | / |
| Length of arm | m³ | / | |
| Bucket capacity | m³ | / | |
