Good Condition XCMG 60DA Used Excavator For Sale
Rated power
36.2kw/2100rpm
Operation Weight
6010Kg
Bucket capacity
0.23m³
XE60DA
The excavator with short-tail design can apply to the narrow work conditions. The engine powertrain is featured with stable torque output, low fuel consumption and low noise. The load hydraulic sensitive system allows for improved maneuverability of compound actions, faster response speed, accurate control and small impact. It can strengthen the local area of boom and arm bearing high stress, and meanwhile adjust the structure, disperse stress and improve the service life. The standard new-type bucket and reduced bucket depth make unloading quicker and faster.It is easy to achieve fine work such as flat land. It is widely used in small earth and stone works, municipal construction, road repair, concrete crushing, buried cables, farmland water conservancy construction, garden cultivation and river channel dredging.
PARAMETERS
| Sales model | Unit | Measurement | |
|---|---|---|---|
| Operating weight | Kg | 6010 | |
| Bucket capacity | m³ | 0.23 | |
| Engine | Model | / | 4TNV94L-BVXG |
| Direct injection | / | √ | |
| Four strokes | / | √ | |
| Water cooling | / | √ | |
| Turbo-charging | / | × | |
| Air cooled | / | 4 | |
| No. of cylinders | / | 36.2/2100 | |
| Output power | kw/rpm | 207.4/1000 | |
| Maximum torque/speed | N.m/rpm | 3.054 | |
| Displacement | L | 4.2/2.2 | |
| Main performance | Travel speed | km/h | 10 |
| Swing speed | r/min | 35 | |
| Gradeability | ° | 32.5 | |
| Ground pressure | kPa | 48.3 | |
| Bucket digging force | kN | 32.5 | |
| Arm digging force | kN | 50.5 | |
| Maximum tractive force | kN | 151.2 | |
| Hydraulic system | Rated flow of main pump | / | 24.5 |
| Rated flow of main pump | L/min | 24.5 | |
| Main safety valve pressure | MPa | 24 | |
| Travel system pressure | MPa | 3.5 | |
| Swing system pressure | MPa | 110 | |
| Pilot system pressure | MPa | 77 | |
| Oil Capacity | Fuel tank capacity | L | 12 |
| Hydraulic tank capacity | L | 5860 | |
| Engine oil capacity | L | 1920 | |
| Appearance size | A Overall length | mm | 2585 |
| B Overall width | mm | 1780 | |
| C Overall height | mm | 1920 | |
| D Width of platform | mm | 400 | |
| E Track length | mm | 1990 | |
| F Overall width of chassis | mm | 1500 | |
| G Track width | mm | 700 | |
| H Length to center of rollers | mm | 385 | |
| I Track gauge | mm | 1920×340 | |
| J Counterweight clearance | mm | 5630 | |
| K Min. ground clearance | mm | 3945 | |
| L Min. tail swing radius | mm | 3830 | |
| M Track height | mm | 2680 | |
| Working scope | A Max. digging height | mm | 6130 |
| B Max. dumping height | mm | 2460 | |
| C Max. digging depth | mm | 1670 | |
| D Maximum depth cut for 2240mm(8 ft) level bottom | mm | 390 | |
| E Max. vertical wall digging depth | mm | 560 | |
| Max. digging radius | mm | 3000 | |
| Min. swing radius | mm | 1600 | |
| Standard configuration | Length of boom | mm | 0.23 |
| Length of arm | mm | 0.09 Narrow bucket |
|
| Bucket capacity | m³ | 0.2 Strengthened bucket |
|
| Optional configuration | Length of boom | m³ | Breaking hammer, Mechanical quick coupling,Rubber track block |
| Length of arm | m³ | / | |
| Bucket capacity | m³ | / | |
