65T Good Condition Used XE650GK Tracked Excavator For Sale
Rated power
563kw/2000rpm
Operation Weight
64800Kg
Bucket capacity
4.0-4.5m³
XE650GK
This hydraulic excavator can be used for digging, loading, ditching, crushing, drilling, clip cutting, lifting and other functions, which has played an increasingly important role in hydropower, transportation, municipal, garden, farmland reconstruction, oil pipeline and other small-scale construction and production field. The engine features low energy consumption, rapid response, accurate control and small impact, and maintains strong digging force and excellent operating efficiency. By adopting brand new generation of load sensing hydraulic system, the system pressure loss is much less. With three major structural parts upgraded and optimized, it is more reliable and durable. Witn fully open rear hood and side door, daily maintenance points are within reach.
PARAMETERS
| Sales model | Unit | Measurement | |
| Operating weight | Kg | 64800 | |
| Bucket capacity | m³ | 4.0～4.5 | |
| Engine | Model | / | M15 |
| Direct injection | / | √ | |
| Four strokes | / | √ | |
| Water cooling | / | √ | |
| Turbo-charging | / | √ | |
| Air cooled | / | √ | |
| No. of cylinders | / | 6 | |
| Output power | kw/rpm | 563/2000 | |
| Maximum torque/speed | N.m/rpm | 2900/1200 | |
| Displacement | L | 14.5 | |
| Main performance | Travel speed | km/h | 4.5/2.7 |
| Swing speed | r/min | 7.2 | |
| Gradeability | ° | ≤35 | |
| Ground pressure | kPa | 105 | |
| Bucket digging force | kN | 346 | |
| Arm digging force | kN | 310 | |
| Maximum traction | kN | 463 | |
| Hydraulic system | Main pump | / | 2×plunger pump |
| Rated flow of main pump | L/min | 2×462 | |
| Main safety valve pressure | MPa | 34.3/37 | |
| Travel system pressure | MPa | 34.3 | |
| Rotary system pressure | MPa | 32 | |
| Pilot system pressure | MPa | 3.9 | |
| Oil Capacity | Fuel tank capacity | L | 800 |
| Hydraulic tank capacity | L | 650 | |
| Engine oil capacity | L | 56 | |
| Appearance size | A Overall length | mm | 12900 |
| B Overall width | mm | 4005 | |
| C Overall height | mm | 4430 | |
| D Width of platform | mm | 3400 | |
| E Track length | mm | 5730 | |
| F Overall width of chassis | mm | 3500(excluding pedals) | |
| G Track width | mm | 600 | |
| H Length to center of rollers | mm | 4610 | |
| I Track gauge | mm | 2900 | |
| J Counterweight clearance | mm | 1560 | |
| K Min. ground clearance | mm | 615 | |
| L Min. tail swing radius | mm | 4110 | |
| M Track height | mm | 1296 | |
| Working scope | A Max. digging height | mm | 11410 |
| B Max. dumping height | mm | 7455 | |
| C Max. digging depth | mm | 6710 | |
| D Maximum depth cut for 2240mm(8 ft) level bottom | mm | 7255 | |
| E Max. vertical wall digging depth | mm | / | |
| F Max. digging radius | mm | 12240 | |
| Min. swing radius | mm | 5175 | |
| Standard configuration | Length of boom | mm | 7100 |
| Length of arm | mm | 2900 | |
| Bucket capacity | m³ | 4.0 | |
| Optional configuration | Length of boom | m³ | – |
| Length of arm | m³ | – | |
| Bucket capacity | m³ | 4.5 | |
